YH-1001 Nodular Cast Iron Soft Sealing Gate Valve

【Core Advantages】
YH-1001 nodular cast iron soft sealing gate valve realizes bidirectional zero leakage, solving weeping defects of traditional metal hard-seal gate valves. Fully EPDM coated wedge fits valve seat tightly.Non-rising stem saves installation space with low operation torque, the ideal ductile iron gate valve for municipal water engineering.

【Product Features】
• Nominal Pressure: 1.6 MPa
• Working Medium: Water, Non-causticity liquid.
• Working Temperature: 0°C - 80°C
• Parallel Pipe Thread to ISO228

【Applications】
Suitable for municipal waterworks, fire protection, agricultural irrigation and industrial water treatment. Supports underground buried installation and indoor pump room layout, favored by water utilities and property contractors.

【FAQs & Solutions】
Q: What is soft sealing?
A: The wedge gate is fully wrapped by EPDM rubber to form watertight seal, different from slightly leaking metal-to-metal gate valves.
Q: Can it be used for flow throttling?
A: No, only full open/closed isolation; throttling damages rubber coating, use globe valves for flow regulation.

【Important Notes】
This valve is for on/off isolation only; do not use it for flow throttling.
For buried installation, use a valve box and extension spindle; ensure adequate drainage around the valve.
Install with sufficient clearance above the handwheel for operation and maintenance.
Do not exceed 80°C; not for steam, gas, oils, or chemically aggressive media.
Operate the valve at least once every 1–3 months to prevent stem seizure.
When closing, turn until firm contact is made; do not use a pipe extension for extra force.
